Description
The Rosslare AC‑425‑BU is an enclosed, expandable 4‑door access control panel designed for small‑to‑medium systems that need networked access control.
Features
- Supports 4 readers and 4 doors out of the box; expandable to 8 readers using an MD‑D04B expansion module
- Stores up to 30,000 active credentials and 20,000 offline event log records in non‑volatile memory
- Works with Rosslare AxTraxNG or AxTraxPro software for configuration, networking, and monitoring
- Wiegand or Clock‑&‑Data; 12 VDC supplied to readers, roughly 245-300 mA max per reader depending on model
- Operating temperature: 0 to 49°C (32 to 120°F); humidity: 0-85% non‑condensing
- Enclosure (ME‑1015) approx. 14.3–14.4 x 10.4 x 3.4–3.8 in; weight about 3.4 kg
