Description
AL1024ULXPD4 is a multi-output power supply/charger that converts a 115VAC, 60Hz input into four (4) 24VDC non power-limited outputs.
- Input
- Input 115VAC, 60Hz, 4.2A
- Input fuse rated @ 3.5A/250V
- Output
- 24VDC output
- 10A of continuous supply current for Access Control applications
- 8A of continuous supply current for Fire Alarm applications
- Four (4) fuse protected outputs
- Output fuses are rated @ 3.5A/250VAC
- Filtered and electronically regulated output
- Short circuit and thermal overload protection
- Battery Charging
- Built-in charger for sealed lead acid or gel type batteries
- Automatic switch over to stand-by battery when AC fails
- Maximum charge current: 3.6A
- Zero voltage drop when switched over to battery backup
- (Batteries are sold separately)
- Supervision
- AC fail supervision (form "C" contacts)
- Notification trigger is selectable for 30 seconds (factory set) or 6 hours
- Low battery supervision (form "C" contacts)
- Battery presence supervision (form "C" contacts)
- Visual Indicators
- AC input and DC output LED indicators
- Temperature
- Operating: 0 to 49°C (32 to 120°F)
- Storage: -20 to 70°C ( -4 to 158°F)
- Relative Humidity: 85% +/- 5%
- BTU/Hr. (approx.): 123 BTU/Hr.
- System AC input VA requirement: 483VA
