Description
Vitek 4.0 MegaPixel Passive Infrared (PIR) H.265+ Network Camera with Discreet Illumination
Features
- Vitek VTC-PIR4CN-4
- 1/3" 4.0 Megapixel CMOS Image Sensor Providing a High Definition Image in Low Light Situations
- Up to 25fps @ 4MP (2560 x 1440), 3MP (2304 x 1296), 1080P (1920 x 1080), 720P (1280 x 720), D1, CIF, 480 ~ 240
- 3.7mm Fixed Iris Lens
- 36pcs IR with up to 33' (10m) IR Range
- Sleek, Compact Design
- Discreet IR Illumination, Nearly Undetectable in Low Light Environments
- 95° Wide Angle - Suitable for Nearly All Indoor Surveillance Monitoring Environments
- True >100dB Wide Dynamic Range
- True Day / Night
- XD-DNR (3D & 2D-DNR) Noise Reduction
- Built-in Mic + 1 Ch. Audio Out
- 16ft. Audio Pick-up Range (5m)
- Motion Detection / Region of Interest (up to 8 Configurable Areas) - Each Region to be Configured Separately
- Dual Stream, H.265+ / H.265 / H.264+ / H.264 Compression
- MicroSD Card Slot for Local Recording (Up to 256GB)
- Remote Viewing via VMS (Microsoft Edge, Chrome, Firefox, and Safari, and iOS & Android Apps)
- ONVIF Compliant
- No Plug-in Req'd, Direct Set-up / Live View / Playback / Record from Browser
- Built-in Easy Wall Mount Included
- 12VDC & PoE (Power over Ethernet) Operation
- 3-Year Warranty
Specifications
- Image Sensor 1/3" 4MP
- Max. Resolution 2560 (H) x 1440 (V)
- ROM / RAM 16MB / 64MB
- Electronic Shutter Speed Auto / Manual
- Min Illumination Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
- S /N Ratio 38dB
- IRs / Illumination Distance 36 SMD Type IRs / 33' IR (10m)
- Illumination On / Off Control Auto / Manual
- Lens Type / Focal Length Pinhole / 3.7mm
- Field of View 95°
- Compression H.265+ / H.265 / H.264+ / H.264
- Video Frame Rate Main Stream: 2560 x 1440 @ 25fps / 1080p (1920 x 1080) @ 25fps / 720p (1280 x 720) @ 25fps
- Sub Stream: 720 x 576 @ 25 fps / 352 x 288 @ 25 fps
- Stream Capability 2 Streams
- Resolution 4MP (2560 x 1440), 1080p (1920 x 1080), 720p (1280 x 720), D1 (720 x 576), CIF (352 x 288)
- Bit Rate Control CBR / VBR
- Video Bit Rate Main Stream: 512 / 1024 / 1536 / 2048 / 3072 / 4096 kbps, Sub Stream: 512 / 1024 kbps
- Microphone Built-in microphone — Supports 16' pick-up range (5m)
- Audio Supports Audio Out
- Day / Night Auto / Manual
- WDR >100dB
- Other Features BLC, HLC, Smart Illum., Defog, Image Mirror, Image Flip, White Balance + Gain Control (Auto/Manual)
- Noise Reduction 3D DNR / 2D DNR
- Motion Detection Yes
- Region of Interest (Rol) Yes (8 Areas)
- Privacy Masking Yes (5 Areas)
- Network RJ-45 (10M/100M Base -T)
- Cyber Security Video / Firmware Encryption, Configuration Encryption, IP / MAC Filtering, 802. 1, Trusted Upgrade
- Protocol IPv4, HTTP, TCP / UDP, RTSP, DHCP
- Interoperability ONVIF (Profile S / Profile T), P2P
- Storage MicroSD Card Support (up to 256GB)
- Browsers Microsoft Edge, Chrome, Firefox, Safari
- Power Supply 12V DC/PoE (802.3af)
- Power Consumption <5W
- Operating Conditions (Storage) 14 ~ 122°F / -10 ~ 50°C / Less than 95% RH (14 ~ 122°F / -10 ~ 60°C / Less than 95% RH)
- Dimensions (H x W x D) 3.5" x 2.0" x 1.5" (89 x 51 x 38mm)
