Description
Keyscan NETCOM2P Plug-On TCP/IP Communication Adapter Module
Keyscan NETCOM2P is a plug on TCP/IP module that connects directly to a Keyscan access control panel or an off-board communication module. It allows you to establish access control system communication along an existing LAN/WAN network.Keyscan NETCOM2P works seamlessly with Keyscan CIM (Communication Interlink Module). The NETCOM2P plugs directly onto Keyscan's CIM communication module to establish network communication to the server among multiple ACUs along a CAN Bus network.
Features
- Where higher security is required for communication, use the NETCOM6P with AES Rijndael (NIST approved) encryption algorithm
- A user-defined encryption key, which can be can be 128 bits, 192 bits, or 256 bits, minimizes the possibility of communication breach
- Includes a Keyscan NETCOM Program Tool utility for custom installation programming
- Also available as an off-board module, NETCOM2 for legacy panels and select integrations
- Fast and easy installation for each ACU
- Requires Static IP addresses for proper operation
- Simplifies both installation and maintenance procedures
- Easy to program with included utility
Specifications
- Dimensions NETCOM2P/6P = 1.625" x 1.9375" (41mm x 49mm)
- Input power through ACU 140 mA, + ACU 130 mA = 270 mA
- Input power through CIM 140 mA + CIM 150 mA = 290 mA
- Network interface RJ45 10/100 Ethernet
- Agency approvals Ethernet Socket Complies with Class B limits of EN 55022 : 1998 Direct & Indirect ESD Complies with EN 55024 : 1998
- Environmental tolerances Suitable for commercial and industrial applications
- Operating temperature 5° to 70°C (41° to 158°F)
