Description
The Wheelock Eluxa weatherproof series EL3RSPK/EL4XSPK speaker and EL3RSPST/EL4XSPST speaker-strobe appliances are designed for easy installation with a pre-wire capable EL3RBB mounting plate, or EL4XBB back box. All Eluxa weatherproof models are for indoor/outdoor use and wall or ceiling mount. The EL3RSPK/EL4XSPK and EL3RSPST/EL4XSPST Series Multi-Candela Speaker Strobes are designed for multiple power requirements with high dBA output at each power tap. The design incorporates a high efficiency speaker for maximum output at minimum power across a frequency range of 400-4000Hz.
Rugged
The cutting-edge solution delivers optimal performance thanks to its
NEMA type 3R and 4X ratings, which make it resistant to corrosion and ice
formation. The IP54 and IP66 ratings provide superior protection against
dust and water, making it ideal for areas of high humidity, extreme heat, or
severe cold.
Energy Efficient
With six candela settings in a single device, Eluxa features one of the
industry's lowest current draws across the full candela range. The Eluxa
outdoor product line reduces overall power consumption, allowing for
more appliances on each circuit (NAC) and fewer power supplies.
Compliance and Approvals
- Certified to NEMA type 3R | 4X
- IP54 |IP66 Certified |Tested to IP67
- NFPA 72 2016 (Meets maximum light pulse duration of 20 ms)
- IEC 60529 2nd edition + amendment 3- August 2013
- FCC Part 15B / ICES-003- Class A
- UL 50 13th edition- October 2020
- UL 50E 3rd edition- October 2020
- UL464 11th edition: CAN/ULC 525 5th edition- May 2023
- UL1480 7th edition: CAN/ULC 541 5th edition- May 2023
- UL1638 6th edition: CAN/ULC 526 5th edition- April 2023
- California State Fire Marshal (CSFM)
- Factory Mutual (FM)
- ADA/NFPA/ANSI/OSHA
