Description
Vitek VT-WB5900 Air Series High Speed 5.8GHz PoE Wireless Bridge with Point-to-Multi-Point (P2MP) Topology, 3.1 Mile Range
VITEK Air Series High Speed 5.8GHz Wireless Bridge with Point-to-Multi-Point (P2MP) Topology!With high speed transmission of 867Mbps and a wireless range of 3.1 miles (5km), the VITEK VT-WB5900 eliminates the need for expensive and troublesome long-distance cables in areas where CCTV monitoring and rigorous surveillance take place. This small, lightweight and durable unit is easy-to-install and easy to use with an innovative and straightforward 10-button plug-and-play dip switch that facilitates the creation of a robust wireless network without a computer. Set-up can be simply configured for point-to-point or point-to-multipoint topology depending on the application, with up to 128 IP group configurations.
Features
- Advanced Qualcomm QCA9563 + QCA9886 Chipset
- 128MB DDR2 Memory with 16MB Flash Storage
- High Speed Wireless Transmission with 867Mbps of data throughput
- Low interference, High Stability, 3.1 Mile (5km) Range
- Tool-free installation, with no computer necessary
- Innovative and easy-to-use 10-Switch DIP Function, automatically syncs AP and CPE points
- Wirelessly connect up to 4 CPE points to one AP point for true Point-to-Multi-Point (P2MP) Topology!
- 128 IP Groups, Automatic Matching Transmission
- Compact and stylish exterior is made with durable, weather-resistant ABS and PC Material (IP65 rating)
- Wired Equivalent Privacy (WEP), SNMP Management Information Base (MIB), Telnet, and Serial Management
- 5180MHz~5240MHz / 5745MHz~5825MHz Channel
- 16Dbi Antenna Gain with Horizontal/Vertical Polarization and 4900~6100MHz
- WEP 64/128bits, WPA, WPA2, 802.1x Security Encryption
- IEEE802.11a, IEEE802.11n, IEEE802.3u, IEEE802.11ac Standards
- Dual 10/100/1000Mbps Ethernet Ports
- PoE24V (1A) Injector Power Supply Included
- 3-Year Warranty
Specifications
- Chipset QCA9563 + QCA9886
- IC SKY85728*2
- Memory / Storage 128MByte DDR2 / 16MB Flash
- Bandwidth 867Mbps
- Wireless Range Up to 3.1 Miles (5km)
- Wired Port 2x - 10/100/1000Mbps (LAN)
- Modulation OFDM BPSK, QPSK, 16-QAM, 64-QAM, 256QAM, DBPSK, DQPSK, CCK
- Standard IEEE802.11a,IEEE802.11n,IEEE802.3u,IEEE802.11ac
- Channel 5180-5240GHz / 5745-5825GHz
- RF@25 ±2dB Sensitivity 802.11a 6-24Mbps (26±2dBm), 36-48Mbps (25±2dBm), 54Mbps (24±2dBm)
- RF@25 ±2dB Sensitivity 802.11AC HT20 MCS 0-3 (26±2dBm), MCS 4 (25±2dBm), MCS 5 (24.5±2dBm), MCS 6 (24±2dBm), MCS 7 (23.5±2dBm)
- RF@25 ±2dB Sensitivity 802.11AC HT40 MCS 0-3 (25±2dBm), MCS 4 (24.5±2dBm), MCS 5 (24±2dBm), MCS 6 (23.5±2dBm), MCS 7 (23±2dBm)
- RF@25 ±2dB Sensitivity 802.11AC HT80 MCS 0-3 (18±2dBm), MCS 4 (18±2dBm), MCS 5 (18±2dBm), MCS 6 (18±2dBm), MCS 7 (18±2dBm)
- Sensitivity 802.11a 6Mbps ≤ -89 / 54Mbps ≤ -73
- Sensitivity 802.11AC HT20 MCS 0 ≤ -94; MCS 7 ≤ -76 / HT40 MCS 0 ≤ -92; MCS 7 ≤ -76 / HT80 MCS 0 ≤ -90; MCS 7 ≤ -67
- Antenna Frequency 4900~6100MHz
- Antenna Polarization Vertical / Horizon
- Antenna Gain 16DBi
- Management WEP, SNMP MIB, Serial, Telnet
- Security (Encryption) WEP 64 / 128bits, WPA, WPA2, 802.1x
- Ingress Protection IP65
- Power Dissipation ≤7W
- Power Input POE 24V 1A
- Operating Temperature -22.0~165°F / -30~65°C
- Humidity ≤95% Non-condensed
- Dimensions / Weight 8 x 8 x 5.21 / 1.1lb (205 x 205 x 132.3mm / 0.5kg)
