Description
Wheelock MIZ piezoelectric mini horns are compact electronic alarm appliances that are listed under UL Standard 464 for Audible Appliances in Public Mode Fire Protection Systems. The MIZ-24S models provide a field selectable Continuous or Code 3 horn tone when connected directly to a fire alarm control panel. They can also provide a synchronized Code 3 horn tone using the Wheelock DSM sync modules or Wheelock power supplies. The MIZ appliances are attractive and offer high sound output along with low current draw. Color choices of red or off-white will blend with any décor.
Features
- Approvals include: UL Standard 464, CAN/ULC-S525-07, California State Fire Marshal (CSFM), New York City (MEA), and Factory Mutual (FM)
- Field-selectable settings for Temporal (Code 3) or Continuous Horn
- Synchronized Code 3 horn when used with Wheelock sync module
- Designed to meet or exceed NFPA/ANSI standards
- Convenient mounting to any standard single-gang box
- Beauty plugs to cover mounting screws
- No additional trim plate required for flush mounting
- Fast installation with In/Out screw terminals using #12 to #18 AWG
- High sound output with low current draw
- Available in red or off-white color
Applications
- Individual rooms
- Apartments
- Hotels
- Motels
- Offices
