Description
AL1012ULX is a power supply/charger that converts a 115VAC, 60Hz input into a single 12VDC non-power limited output.
- Input
- Input 115VAC, 60Hz, 2.6A
- Input fuse rated @ 5A/250V
- Output
- 12VDC output
- 10A continuous supply current
- Output fuse rated @ 15A/32V
- Filtered and electronically regulated output
- Short circuit and thermal overload protection
- Battery Charging
- Built-in charger for sealed lead acid or gel type batteries
- Maximum charge current: 0.7A
- Automatic switch over to stand-by battery when AC fails
- Zero voltage drop when switched over to battery backup
- (Batteries are sold separately)
- Supervision
- AC fail supervision (form "C" contacts)
- Notification trigger is selectable for 30 seconds (factory set) or 6 hours
- Low battery supervision (form "C" contacts)
- Battery presence supervision (form "C" contacts)
- Visual Indicators
- AC input and DC output LED indicators
- Temperature
- Operating: 0 to 49° C (32 to 120° F )
- Storage: - 20 to 70° C ( - 4 to 158° F)
- Relative Humidity: 85% +/- 5%
- BTU/Hr (approx): 61 BTU/Hr
- System AC input VA requirement: 299VA
