Bosch DS160 Request-to-Exit Sensor, Sounder, Light Gray
The DS160 is specifically designed for Request-to-exit (REX) applications. With features such as timers, door monitor with sounder alert, and pointable coverage, the DS160 has the flexibility to meet the most stringent REX requirements. The exclusive Sequential Logic Input (SLI) provides added security that is not offered in any other REX device.
Features
- Door monitor with sounder alert
- Sequential Logic Input (SLI)
- Internal vertical pointability
- Wrap-around coverage pattern with precise pattern control
- Up to 64 second adjustable latch time
- Selectable relay trigger mode
- Selectable fail safe/fail secure modes
- Adjustable sounder volume
- Activation LED
Specifications
- Operating Temperature -29°C to +49°C (-20°F to +120°F)
For UL Certificated installations, 0°C to +49°C
(+32°F to +120°F)
- Radio Frequency Interference (RFI) Immunity No alarm or setup on critical frequencies in the range from 26 MHz to 1000 MHz at 50 V/m
Complies with Environmental Class II (EN50130-5)
- Dimensions 4.5 cm x 17.1cm x 4.4 cm
(1.80 in. x 6.75 in. x 1.75 in.)
- Material High impact ABS plastic enclosure
- Power Loss Default Programmable fail-safe or fail-secure modes
- Timer Programmable reset accumulative or non-reset counting mode
- Current Draw 8 mA nominal standby current, 39 mA at 12 VDC in alarm
- Voltage 12 VAC or VDC to 30 VAC or VDC
- Alarm Output Two Form C relay contacts each rated 1 A at 30 VAC or VDC for resistive loads
- Indicators 1 activation LED
- Relay Latch Time Adjustable from 0.5 sec to 64 sec.
