Description
UltraLine® 74R2-130 Electric Strike for Rim Exit Devices with Pullman Type Latchbolts
74R2 Electric Strike is designed for narrow stile rim exit devices with 1/2" [12.7 mm] Pullman latchbolts. Designed for use in aluminum applications.
Open electrically under 25 lbs [11.3 kg] of preload. Preload is pressure exerted on doors by air conditioning systems, warping or misaligned hardware which can disable common electric strikes.
Function
These non-handed strikes feature an ultra-compact design and adjustable stainless steel keepers with over 1,500 lbs [680.4 kg] of holding force in fail secure mode. The strikes release electrically with up to 25 lbs of door preload. Single solenoid operates on 12/16/24 VDC power. Provides electrical remote control, allowing door to open without actuation of the exit device.
Features
- Finish: To match 628 Clear Anodized
- Case: 1-13/32" x 3-3/8" x 1-1/8" deep [35.7 mm x 85.7 mm x 28.6 mm deep]
- Strike Opening:
Bolt retaining keeper is stainless steel
5/8" x 1-7/16" x 1/2" deep [15.9 mm x 36.5 mm x 12.7 mm deep] - Faceplate:
Not separate
1-5/8" x 9 x 1/2" [41.3 mm x 228.6 mm x 12.7 mm] - Latchbolt Projection: 1/2" [12.7 mm]
- Individually boxed with mounting plate shims, mounting screws, and installation instructions
