Description
The Altronix Netway3024PX converts 802.3bt (90W) to simultaneous 24VDC/1A and 802.3at PoE+ (25W) outputs for applications including PoE cameras and external microphones, control boards, switching equipment, and more for 60W total output.
Specifications
- 802.3bt (90W) 4PPoE
- Converts 802.3bt (90W) to 802.3at PoE+ (25W) and 24VDC (25W/1A) simultaneously
- Single port rated up to 25W max.
- IEEE 802.3af, 802.3at compliant
- Connectivity: RJ45, auto-crossover
- Wire type: 4-pair CAT5e
- Distance: up to 100m
- Speed: 10/100/1000 Mbps
- 24VDC up to 1A
- 60W total power combined with PoE
- Auto detection and protection of legacy non-PoE cameras/devices
- Compact insulated housing
- Yellow and Green LEDs: IP Link status, 10/100/1000 Base-T/active
- Green LED: PoE ON
- Red LED: Power ON
- Operating Temperature (90W): -40°C to 75°C (-40°F to 167°F)
- Storage temperature: -40°C to 75°C (-40°F to 167°F)
- Relative Humidity 85% +/- 5%
- Operating Altitude: - 304.8 to 2,000m
