Description
AL400ULPD4CB is a multi-output power supply/charger that converts a 115VAC/60Hz input into four (4) Class 2 Rated 12VDC or 24VDC power limited outputs.
Features
- Input 115VAC, 60Hz, 3.5A
- Input fuse rated @ 3.5A/250V
- 12VDC or 24VDC selectable output
- 12VDC @ 4A or 24VDC @ 3A supply current
- Four (4) Class 2 Rated PTC protected power limited outputs (auto-resettable)
- Outputs are rated @ 2.5A
- Filtered and electronically regulated outputs
- Short circuit and thermal overload protection
- Built-in charger for sealed lead acid or gel type batteries (Batteries are sold separately)
- Automatic switch over to stand-by battery when AC fails
- Maximum charge current: 0.7A
- Zero voltage drop when switched over to battery backup
- AC fail supervision (form "C" contacts)
- Notification trigger is selectable for 30 seconds (factory set) or 6 hours
- Low battery supervision (form "C" contacts)
- Battery presence supervision (form "C" contacts)
- AC input and DC output LED indicators
- System AC input VA requirement: 402.5VA
