Description
PTH-4Q-DPS Four (4) Conductor Power Transfer Hinge with Door Status Contact
28 gauge - 1-pair 1 Amp, 1-pair 250 mA @ 12/24V AC/DC
Door Status Contact: 250 mA @ 30VDC
4.5" x 4.5" standard weight, 626 Dull Chrome
Power Transfer Hinge Application
Installed in the center hinge position of the door, PTH Power Transfer Hinges provide the concealed wires required
to transfer power from the frame to electric hardware in the door for control and monitoring capability.
Features
- 5' Ft Cable
- UL10B Listed for 3 Hour Fire Rated Doors. If the hinge you are presently using does not bear the mark 'F' it is not listed for use with fire rated doors.
- 800,000 cycles. 8 times UL test criteria.
- Wire Replacement Warranty
